Running a simulation

Source: vignettes/run-simulation.Rmd
run-simulation.Rmd

Running individual simulation and retrieving the results

Once the simulation is loaded (see Loading a simulation and accessing entities), it can be run using runSimulations() to produce an object of the class SimulationResults. Keep in mind that runSimulations() produces a list of SimulationResults objects.

library(ospsuite)

# Load the simulation
simFilePath <- system.file("extdata", "Aciclovir.pkml", package = "ospsuite")
sim <- loadSimulation(simFilePath)

simulationResults <- runSimulations(simulations = sim)
# Extract `SimulationResults` by simulation id
simulationResults <- simulationResults[[sim$id]]
print(simulationResults)
#> <SimulationResults>
#>   • Number of individuals: 1
#> For paths:
#>   • Organism|PeripheralVenousBlood|Aciclovir|Plasma (Peripheral Venous Blood)

The advantage of storing the results in a object is the option to keep different results of the same simulation produced with different settings (e.g., model parameters).

Simulated time-value pairs for a specific output from the SimulationResults-object can be accessed with the method getOutputValues. The user can provide either the path(s) of the output (which can be a molecule, a parameter, or an observer), or the object(s) of the type Molecule, Parameter, or Quantity (for observers) with the argument quantitiesOrPaths. If no output is specified, all outputs available in the simulation results are returned.

The paths of all available outputs can be accessed via

simulationResults$allQuantityPaths
#> [1] "Organism|PeripheralVenousBlood|Aciclovir|Plasma (Peripheral Venous Blood)"

getOutputValues returns a list with two entries: data and metadata:

  • data is a dataframe with two predefined columns (IndividualId and Time) as well as one column for each requested output

    • IndividualId (not relevant for an individual simulation)
    • Time a vector with simulated time values (in minutes, equal for all outputs)
    • a vector with simulated entries for each output requested.

  • metaData is a list containing one entry for each requested output. Each entry contains information pertinent to the output such as its dimension or the unit.

# Get simulated results by path
resultsPath <- simulationResults$allQuantityPaths[[1]]
print(resultsPath)
#> [1] "Organism|PeripheralVenousBlood|Aciclovir|Plasma (Peripheral Venous Blood)"

resultsData <- getOutputValues(
  simulationResults,
  quantitiesOrPaths = resultsPath
)

resultsTime <- resultsData$data$Time
resultsValues <- resultsData$data$`Organism|PeripheralVenousBlood|Aciclovir|Plasma (Peripheral Venous Blood)`

plot(resultsTime, resultsValues, type = "l")

The results can be stored in and imported from a *.csv file with the methods exportResultsToCSV and importResultsFromCSV.

# Load and run the simulation
simFilePath <- system.file("extdata", "Aciclovir.pkml", package = "ospsuite")
sim <- loadSimulation(simFilePath)
# `runSimulations` returns a list of `SimulationResults`. For single simulation,
# we directly extract the first element, as only one object is created.
simulationResults <- runSimulations(simulations = sim)[[1]]

# Export to csv
csvResultsPath <- system.file("extdata", "SimResults.csv", package = "ospsuite")
exportResultsToCSV(results = simulationResults, filePath = csvResultsPath)

# Load from csv
resultsLoaded <- importResultsFromCSV(
  filePaths = csvResultsPath,
  simulation = sim
)
print(resultsLoaded)
#> <SimulationResults>
#>   • Number of individuals: 1
#> For paths:
#>   • Organism|PeripheralVenousBlood|Aciclovir|Plasma (Peripheral Venous Blood)

Running multiple individual simulations and retrieving the results

In some cases, the user might want to run multiple simulations in parallel. This can be achieved easily by simply passing a list of simulations to the runSimulations() function. However, only individual simulations (i.e., the population argument must remain empty) are supported.

By default, the simulations will be executed in parallel by using up to all cores available on the machine minus 1. So if there are 8 cores and the user simulates 4 simulations, 4 cores will be used. On the other hand, if the user simulates 10 simulations with only 8 cores available, 7 will be used and then the first 3 available.

# Load and run multiple simulations concurrently.
simFilePath <- system.file("extdata", "Aciclovir.pkml", package = "ospsuite")

# We load 3 times the same simulation for convenience. But in real life scenarios,
# they should be different simulations
sim1 <- loadSimulation(simFilePath)
sim2 <- loadSimulation(simFilePath)
sim3 <- loadSimulation(simFilePath)

simulationResults <- runSimulations(simulations = list(sim1, sim2, sim3))

The results in this case will be a named list of SimulationResults-object , i.e. one for each simulation. The names of the entries of the list are the ids of the simulation to which the results correspond. This way, it is easy to retrieve the correct results for the specific simulation

# Get the id of the second simulation
id <- sim2$id
print(id)
#> [1] "ZvwROrOdx0yZQCrOk1jhMA"
# get the corresponding result
sim2Results <- simulationResults[[id]]
print(sim2Results$simulation$id)
#> [1] "ZvwROrOdx0yZQCrOk1jhMA"

Adding new outputs

By default, only outputs that were selected in PK-Sim or MoBi prior to the export of the simulation to pkml are generated. The user can add new outputs to the simulation with the method addOutputs. The outputs can be provided either as objects of the type(s) Molecule, Parameter, or Quantity, or as path strings. The output list is a property of the simulation. After adding or removing outputs, the corresponding simulation needs to be re-run in order to generate updated results.

# Clear the list of generated outputs
clearOutputs(sim)

# Add new outputs as objects
molecule <- getMolecule("Organism|Kidney|Intracellular|Aciclovir", sim)
observer <- getQuantity("Organism|Lumen|Aciclovir|Fraction dissolved", sim)

addOutputs(c(molecule, observer), simulation = sim)

# Add new outputs as path strings
addOutputs(
  c(
    "Organism|Lumen|Stomach|Aciclovir",
    "Organism|PeripheralVenousBlood|Aciclovir|Whole Blood (Peripheral Venous Blood)"
  ),
  simulation = sim
)

# Run simulation
simulationResults <- runSimulations(simulations = sim)

# Retrieve all generated outputs (e.g. omitting the quantitiesOrPaths property
# will return all available values)
resultsData <- getOutputValues(simulationResults)

# Note that "Organism|PeripheralVenousBlood|Aciclovir|Plasma (Peripheral Venous Blood)"
# is not in the list of generated results any more
names(resultsData$data)
#> NULL

clearOutputs() and addOutputs() can be combined with the function setOutputs().

Changing simulation intervals

The simulation interval (i.e., the simulation times at which results are stored) are stored as the property $outputSchema of a Simulation object.

print(sim$outputSchema)
#> <OutputSchema>
#>
#> ── Output intervals ──
#>
#> <Interval>
#>   • Name: Simulation interval high resolution
#>   • Start time: 0.00e+00 [min]
#>   • End time: 15.00 [min]
#>   • Resolution: 1.00 [pts/min]
#> <Interval>
#>   • Name: Simulation Interval 1
#>   • Start time: 15.00 [min]
#>   • End time: 1440.00 [min]
#>   • Resolution: 0.33 [pts/min]
#> <Interval>
#>   • Name: Simulation Interval 2
#>   • Start time: 120.00 [min]
#>   • End time: 1440.00 [min]
#>   • Resolution: 0.07 [pts/min]

To change the simulation interval, the user can use one of the functions clearOutputIntervals(), addOutputInterval(), and setOutputInterval().

# Remove all output intervals - simulation not possible!
clearOutputIntervals(simulation = sim)
runSimulations(simulations = sim)
#> Error in `do.call()`:
#> ! Type:    OSPSuite.Utility.Exceptions.OSPSuiteException
#> Message: Time points output schema is empty
#> Method:  Void EvaluateCppCallResult(Boolean, System.String)
#> Stack trace:
#>    at OSPSuite.SimModel.PInvokeHelper.EvaluateCppCallResult(Boolean success, String errorMessage)
#>    at OSPSuite.SimModel.Simulation.evaluateCppCallResult(Boolean success, String errorMessage)
#>    at OSPSuite.SimModel.Simulation.RunSimulation()
#>    at OSPSuite.Core.Domain.Services.SimModelManager.simulate()
#>    at System.Threading.ExecutionContext.RunFromThreadPoolDispatchLoop(Thread threadPoolThread, ExecutionContext executionContext, ContextCallback callback, Object state)
#> --- End of stack trace from previous location ---
#>    at System.Threading.ExecutionContext.RunFromThreadPoolDispatchLoop(Thread threadPoolThread, ExecutionContext executionContext, ContextCallback callback, Object state)
#>    at System.Threading.Tasks.Task.ExecuteWithThreadLocal(Task& currentTaskSlot, Thread threadPoolThread)
#> --- End of stack trace fr

# Add an interval
addOutputInterval(
  simulation = sim,
  startTime = 0,
  endTime = 20,
  resolution = 60,
  intervalName = "highRes"
)
print(sim$outputSchema)
#> <OutputSchema>
#>
#> ── Output intervals ──
#>
#> <Interval>
#>   • Name: highRes
#>   • Start time: 0.00e+00 [min]
#>   • End time: 20.00 [min]
#>   • Resolution: 60.00 [pts/min]

# Add a second interval
addOutputInterval(
  simulation = sim,
  startTime = 30,
  endTime = 2000,
  resolution = 4,
  intervalName = "lowRes"
)
print(sim$outputSchema)
#> <OutputSchema>
#>
#> ── Output intervals ──
#>
#> <Interval>
#>   • Name: highRes
#>   • Start time: 0.00e+00 [min]
#>   • End time: 20.00 [min]
#>   • Resolution: 60.00 [pts/min]
#> <Interval>
#>   • Name: lowRes
#>   • Start time: 30.00 [min]
#>   • End time: 2000.00 [min]
#>   • Resolution: 4.00 [pts/min]

# Replace the existing interval(s) with a new one
setOutputInterval(
  simulation = sim,
  startTime = 0,
  endTime = 2000,
  resolution = 4
)
print(sim$outputSchema)
#> <OutputSchema>
#>
#> ── Output intervals ──
#>
#> <Interval>
#>   • Name: Output interval
#>   • Start time: 0.00e+00 [min]
#>   • End time: 2000.00 [min]
#>   • Resolution: 4.00 [pts/min]

Adjusting solver settings

The solver settings control the numerical integration algorithm used to solve the differential equations in the simulation. These settings can be accessed and modified through the $solver property of a Simulation object.

# View current solver settings
print(sim$solver)
#> <SolverSettings>
#>   • useJacobian: TRUE
#>   • h0: 1e-10
#>   • hMin: 0
#>   • hMax: 60
#>   • mxStep: 100000
#>   • relTol: 1e-05
#>   • absTol: 1e-10

In some cases, a simulation may fail to run successfully due to numerical instability or convergence issues. One common approach to resolve such issues is to reduce the solver tolerances, which makes the solver use smaller step sizes and more precise calculations. The two main tolerance parameters are:

  • absTol: Absolute tolerance - controls the accuracy of the solution in absolute terms
  • relTol: Relative tolerance - controls the accuracy of the solution relative to the magnitude of the values
# If a simulation fails to run, try reducing the tolerances
# Reduce absolute tolerance by a factor of 10
sim$solver$absTol <- sim$solver$absTol * 1e-1

# Optionally, the relative tolerance can also be reduced
# sim$solver$relTol <- sim$solver$relTol * 1e-1

# After changing solver settings, re-run the simulation
simulationResults <- runSimulations(simulations = sim)[[1]]

Other solver settings that can be adjusted include:

  • h0: Initial time step size
  • hMin: Minimum step size allowed
  • hMax: Maximum step size allowed
  • mxStep: Maximum number of (internal) steps to be taken by the solver in its attempt to reach the next output time
  • useJacobian: Indicates whether to use the analytically calculated Jacobian matrix during calculations. When disabled, an approximation by difference quotients is used, which is much slower in the majority of cases

For more details on solver properties and their effects, see the MoBi documentation on ODE Solver Properties.
